TriMark Right Hand Lock RV Compartment Storage Baggage Door Latch 2 Key 20599-05

$62.95

Right Hand Black TRIMARK 030-1450 BAGGAGE DOOR LOCK with 2 Keys #2001

THIS LATCH IS FROM THE TRIMARK SERIES 030-1450 AND THE PART NUMBER IS 20599-05

This flush mounted paddle is a redesign of our 030-0450 paddle handle for compartment doors and entrance doors on RV and specialty vehicles. Containing the same proven mechanical details as previous with a modernized look, it can be used in FMVSS 206 applications,  features 2-point remote pivot plate and lock cam actuation.

Approximate size:  Face 6 1/8″ x 3 11/16″ Recommended cut-out  4 45/64″ x 2 15/32″ See print picture for sizes.



Features/Benefits

  • Offers updated styling
  • Paddle is rigid when locked
  • Inside lock detail provides for multiple connection points for use of inside lock and/or powerlock actuation
  • Molded rubber gasket for flange of housing provides resistance to water and dust infiltration

Installation



  • Handle is easy to install with a single 1/4-20 UNC nut (not supplied) and supplied mounting bracket (mounting torque not to exceed 30 in-lbs [3.39 N-m])
  • Can be installed in a wide range of locations in either horizontal or vertical orientations.
  • Retrofits with most 030-0450 flush paddle handles

Material

  • Sturdy zinc die cast alloy housing and paddle
  • Steel components: zinc plated, mild steel
